SRIHOME NVS010+IPC047 10.1 Inch LCD Screen IP66 Waterproof 8CH WiFi NVR 5MP HD CCTV Camera Kit - EU Plug
Adapter Plug: EU Plug
Quantity:
$138.31
Sales Manager: Tracy
tracy@tvcmall.com
tvc-tracy
+86 15817335797
+86 15817335797
30 Days DOA
One-year warranty
Secure Payment
Product Descriptions
SRIHOME NVS010+IPC047 10.1 Inch LCD Screen IP66 Waterproof 8CH WiFi NVR 5MP HD CCTV Camera Kit - EU Plug
- 10.1-Inch LCD Screen with Multi-Touch Control: Provides an interactive and user-friendly interface for easy operation
- 5MP Camera with 8 CH Screen Mirroring: Offers high-definition video and the ability to view up to 8 channels simultaneously
- Extensive Storage Capacity: Supports storage and playback with up to 16TB hard drive (2.5-inch) for ample recording space
- Wireless Bridge Mode: Features a WiFi range of up to 60 meters, allowing flexible camera placement
- Efficient H.265 Compression: 1TB storage can retain footage for approximately 30 days, optimizing space and data management
- Bidirectional Voice Communication: Equipped with a built-in microphone and speaker for two-way audio
- Advanced AI Intelligence: Includes humanoid tracking, motion detection, and alarm functions for enhanced security
- Mobile Phone Remote Access: Enables remote monitoring, intercom, and playback through mobile devices for convenience
- IP66 Waterproof: Ensures durability and reliable performance in both indoor and outdoor environments
Specifications:
| WiFi NVR | Model | NVS010 (WiFi version) |
| Display Screen |
Screen size | 10.1 inch LCD screen |
| Display resolution | 800xRGB (3) x1280 | |
| Touch control | Support multi-touch | |
| Video | Video input | 8 CH |
| Video output | 1 HD, 1 VGA | |
| Compressed format | H265/H264/Smart264 | |
| Coding ability | 8*5M/25fps | |
| Decoding capability | 1*5M/25fps (main stream); 8*D1/25fps (secondary stream) | |
| Decoding format | H265; H.264; | |
| Audio | Audio | Support two-way audio, built-in microphone and speaker |
| Audio output | HDMI and 1 AUX audio output with built-in speaker | |
| Decoding format | G.711U; AAC | |
| Hard Disk | Hard disk interface | 1 SATA interface (2.5 inch hard disk only), SSD & HDD |
| Hard disk capacity | Maximum support 16TB | |
| Recording /Playback |
Recording mode | Timing video recording, alarm video recording |
| Playback mode | Regular playback and APP playback | |
| Backup mode | General backup | |
| Network | WiFi | 2.4 G, for standard camera connection only |
| WAN | RJ45 Wired Connection | |
| Network service | Support DHCP, DNS, DDNS, NTP, UPNP, etc | |
| Alarm | Alarm mode | Motion detection alarm, humanoid detection alarm |
| Alarm reminding | APP push, alarm whistle | |
| External Interface |
Network interface | An RJ45 network interface |
| USB interface | 1 USB2.0 | |
| HDMI interface | 1 | |
| VGA interface | 1 | |
| Audio interface | 1 AUX audio output interface | |
| Power interface | 1 DC 12V 2A (5.5*2.1*10) | |
| APP | Support SriHome APP, IOS and Android remote access | |
| Standard Cameras | ||
| Camera | Model | NVS010-IPC047 |
| System | Main processor | Multi-core high-speed processor |
| Sensor | 1/3-inch, 5 MP HD color CMOS sensor | |
| Compression format | H.265 | |
| Len | Lens parameter | Focal length: 4mm, 5 mp |
| Visible angle | Angle of view: D 110 H 80 V 58 | |
| Video | Resolution | 1920P (2560*1920), VGA (480*360) |
| Frame rate | 15 frames | |
| IR-Cut | Built-in IR-Cut, no color cast indoors and outdoors | |
| Audio | Audio | Built-in Mic and speaker, Support two-way audio |
| Agreement | G711 | |
| Night Vision |
Alarm mode | The default is black and white night vision. When an alarm is detected, the white light is turned on and switches to full color night vision |
| White light mode | Working hours 5:00 p.m to 8:00 a.m, the white light turn on, the brightness can be adjusted, and the night vision is full color | |
| Infrared mode | White light is turned off and switched to normal night vision | |
| Pan-tilt | Tracing | Humanoid tracking is supported |
| Angle of rotation | Horizontal: 340°, vertical: 90° | |
| Alarm | Alarm | Motion detection alarm, humanoid alarm |
| Siren | Alarm whistle can be set | |
| Custom alarm area | Support custom motion detection alarm area to improve alarm accuracy | |
| Wireless | Wireless | 2.4 G (Connect to NVS001E/NVS010 Host Only) |
| Pairing Mode | QR code pairing, Reset button pairing | |
| Others | Product type | Plastic PTZ camera, suitable for indoor and outdoor |
| Power adapter | Input AC: 100 ~ 240V, output DC: 12V | |
| Working temperature | -10 ~ 50℃ | |
| Weight | Net weight 375g (based on actual weight) | |
| Body size | 130 * 110 * 125 mm (length x width x height) | |
Package included:
- 1 x WiFi NVR Host
- 4 x WiFi Camera
- 1 x Power Adapter for NVR
- 4 x Power Adapter for Camera
- 2 x HDD Screw
- 4 x Screw Pack
- 1 x 1m LAN Cable
- 1 x Reset Pin
- 1 x English and Chinese User Manual
See Less
Specifications
Adapter Plug
EU Plug
Brand
SRIHOME
User Manual (Language)
English and Chinese
Gross Weight
3.605kg
Volume Weight
4.257kg
Package Length
32.200cm
Package Width
26.000cm
Package Height
22.700cm
Product packaging
Colored Box
