3P 125A Tuya Smart Home WiFi Circuit Breaker Remote Control Cloud-Managed Intelligent Switch

• 【Smart WiFi Control】Tuya-enabled WiFi circuit breaker for remote control and monitoring of your electrical system through smartphone or voice commands
• 【Versatile Compatibility】Available in 1P, 2P, 3P, and 4P configurations, suitable for various residential and commercial applications
• 【High Current Capacity】Rated currents ranging from 10A to 125A, accommodating different power requirements
• 【Robust Protection】6kA rated short-circuit breaking capacity and 6kV rated impulse withstand voltage for enhanced safety
• 【Durable Performance】Mechanical life exceeding 10,000 operations and electrical life over 6,000 operations for long-term reliability
• 【Wide Operating Temperature】Designed to function effectively in temperatures ranging from -25 to +65℃
• 【Environmental Resistance】Compliant with salt spray and dust resistance standards for durability in various environments

Specifications:

• Standard Compliance: GB/T10963.1, IEC60898-1
• Rated Voltage: AC220V (1P, 2P) / AC400V (3P, 4P)
• Rated Frequency: 50Hz
• Pole Numbers: 1P, 2P, 3P, 4P
• Pollution Degree: 2
• Protection Class: IP20
• Installation Category: II, III
• Operating Temperature: -25 to +65℃
• Frame Size Rated Current: 80A, 125A
• Rated Current Options: 10A, 16A, 20A, 25A, 32A, 40A, 63A, 80A, 100A, 125A
• Instantaneous Tripping Type: C
• Rated Short-circuit Breaking Capacity: 6kA
• Rated Impulse Withstand Voltage: 6kV
• Mechanical Life: > 10,000 operations
• Electrical Life: > 6,000 operations
• EMC Performance: Compliant with GB/T 18449
• Surge Withstand: Compliant with GB/T 17626.5, 4.0KV
• Salt Spray Resistance: Compliant with GB/T2423.17, 48h
• Dust Resistance: Compliant with GB 4208, 8h
• Maximum Wiring Capacity: 50mm²
• Tightening Torque: 4-5Nm
