1P 100A Tuya Smart Home WiFi Circuit Breaker Remote Control Cloud-Managed Intelligent Switch

• 【Smart Wi-Fi Circuit Breaker】Tuya-enabled intelligent circuit breaker for IoT and smart home applications, offering wireless remote control capabilities
• 【Versatile Compatibility】Suitable for various electrical systems, supporting AC220V
• 【High Performance】Features a rated short-circuit breaking capacity of 6kA and a rated impulse withstand voltage of 6kV, ensuring reliable protection
• 【Durable Construction】Boasts a mechanical life exceeding 10,000 operations and an electrical life of over 6,000 operations, guaranteeing long-term reliability
• 【Wide Operating Range】Designed to function effectively in temperatures from -25 to +65℃, suitable for diverse environmental conditions
• 【Enhanced Safety Features】Complies with GB/T 17626.5 for surge protection up to 4.0KV and offers IP20 protection grade for added safety

Specifications:

• Standard Compliance: GB/T10963.1, IEC60898-1
• Rated Voltage: AC220V
• Rated Frequency: 50Hz
• Pole Type: 1P
• Pollution Degree: 2
• Protection Grade: IP20
• Installation Category: II, III
• Operating Temperature: -25 to +65℃
• Frame Size Rated Current: 80A, 125A
• Rated Current: 100A
• Instantaneous Tripping Type: C
• Rated Short-circuit Breaking Capacity: 6kA
• Rated Impulse Withstand Voltage: 6kV
• Mechanical Life: >10,000 operations
• Electrical Life: >6,000 operations
• EMC Performance: Complies with GB/T 18449
• Surge Withstand: Complies with GB/T 17626.5, 4.0KV
• Salt Spray Resistance: Complies with GB/T2423.17, 48h
• Dust Resistance: Complies with GB 4208, 8h
• Maximum Wiring Capacity: 50mm²
• Tightening Torque: 4-5Nm
